AutoCAD is widely used by designers, construction professionals, and engineers, but it's especially valuable for electrical engineers. Its features have been specifically designed to produce precise work that can help electrical engineers stay in compliance with strict safety standards. Learning the software can be challenging, but it's well worth the effort in the long run, helping to make all sorts of projects go much more smoothly.
Live AutoCAD Instructor-led Courses |
||
Course Title | Length | Price (USD) |
AutoCAD Essentials | 3 days | $1,765 |
AutoCAD Advanced | 3 days | $1,765 |
AutoCAD 3D Drawing & Modeling | 3 days | $1,765 |
AutoCAD - 2D Combo | 6 days | $3,215 |
AutoCAD - 2D & 3D Combo | 9 days | $4,695 |
Self-Paced AutoCAD eLearning |
||
Course Title | Length | Price (USD) |
Autodesk, Drafting & Building Design eLearning Bundle | 140 courses | $600 |
Electrical engineers can choose from different versions of AutoCAD, but AutoCAD and AutoCAD LT are the most commonly used. While both offer essential drafting tools, there are key differences.
AutoCAD includes 2D and 3D tools, AI-powered automation, and features that support collaboration. AutoCAD LT, on the other hand, is limited to 2D drafting and documentation. AutoCAD's broader capabilities improve productivity and make it easier to meet industry standards. For example, users can easily modify descriptions from a spreadsheet instead of making manual changes on a drawing. But the biggest difference between the two is that AutoCAD includes access to the Electrical tool set, a must-have for electrical engineers.
Electrical drafting can be complex, requiring precision to create accurate wiring diagrams, circuit board schematics, and layout drawings. Tasks like placing wire numbers and tracking references can be time-consuming parts of the process of creating detailed and precise drafts in AutoCAD. But electrical drafting can be a little simpler when you have the software's Electrical tool set, which automates key functions to save time and improve accuracy.
The Electrical tool set, available only in the full version of AutoCAD, helps electrical engineers streamline their workflow so that they can work more quickly and efficiently. This specialized tool set includes a library of more than 65,000 electrical symbols, making it easy to create detailed diagrams. Engineers can also customize symbols by adjusting colors or characteristics or build new ones using the Symbol Builder. AutoCAD also allows multiple projects to be created from a single drawing, further boosting efficiency.
AutoCAD's built-in features make it easier to design and draw electrical diagrams in a variety of ways. The Circuit Builder helps users visualize power feed circuits and motor control circuits with the help of spreadsheets, templates, and the electrical standards database. Another useful feature is the ability to monitor parent/child relationships by assigning tags to components. AutoCAD also prevents redundant work by letting users pull from a single data source for multiple projects.
Electrical engineers must ensure that their designs comply with safety standards when they're creating an electrical wiring diagram. In AutoCAD, built-in libraries include standard-compliant symbols, making it easier to meet industry regulations. These symbols follow:
As part of its legacy support, AutoCAD also includes JIC and IEC symbols for reference.
Another big advantage of using AutoCAD for electrical engineers is that it has numerous automation tools. Using these features can improve efficiency while maintaining precision. AutoCAD can automate reports, data imports and exports, wire numbering, and tag generation. The title block update utility and Circuit Builder can further enhance productivity,
Proper training in AutoCAD for electrical engineers is essential to help them get the most out of this powerful software, especially considering the precision required to produce high-quality work and safe products. At Certstaffix Training, we offer several AutoCAD courses that are designed to help you master this software quickly and painlessly. Start with the essentials if you're a complete beginner, or try a more advanced course: We have a variety of options, all of which are taught by a live instructor using hands-on exercises to help you learn more quickly. Our courses can even help you prepare to earn the AutoCAD Certified User or Certified Professional credentials. Enroll in one of our training courses today to begin designing a great electrical engineering career for yourself!
